Specifications |
10.1 inch smart center control screen |
|||
|
Product model |
IXP101H1-A133P |
IXP101H1-RK3288 |
IXP101H1-RK3568 |
IXP101H1-RK3576S |
|
resolution |
800*1280 |
|||
|
display scale |
5:8 |
|||
|
Display area |
136*217.2mm |
|||
|
panel type |
IPS |
|||
|
visual angle |
Full perspective |
|||
|
brightness |
500cd/m²(Optional 1000 cd/m²) |
|||
|
Glass thickness |
1.8mm |
|||
|
Glass surface hardness |
>6H |
|||
|
Transmittance of glass |
85% |
|||
|
Touch surface material |
Flat tempered glass |
|||
|
Touch screen type |
capacitance |
|||
|
Touch mode |
5-point touch |
|||
|
Panel protection class |
Front panel IP65, rear cover IP20 |
|||
|
Overall dimensions |
180.7*262.1mm |
|||
|
Case color |
Silver or Black |
|||
|
Program |
Allwinner A133P |
Rockchip RK3288 |
RockchipRK3568 |
Rockchip RK3576S |
|
CPU |
4-Core A53，Clocked at 1.8GHz |
4-Core A17，Clocked at 1.8GHz |
4-Core A55，Clocked at2.0GHz |
4-core Cortex-A72 +4-core Cortex-A53 (Clocked at2.2GHz) |
|
GPU |
GE8300 |
Mali-T764 |
Mali-G52 2EE |
Mali-G52 MC3 |
|
NPU |
NO |
NO |
1TOPS |
3TOPS |
|
Memory + Storage |
1GB+32GB, up to 4GB+128GB |
2GB+32GB, up to 4GB+128GB |
2GB+32GB, up to 8GB+128GB |
4GB+32GB, up to 16GB+256GB |
|
HDMI |
NO |
HDMI 2.0 |
HDMI 2.0 |
HDMI 2.0 |
|
Ethernet |
100Mbps |
Gigabit |
Gigabit |
Gigabit |
|
COM |
Support (optional, choose between COM and Uart6) |
NO |
NO |
NO |
|
CAN |
NO |
NO |
Support (optional, choose between CAN and COM6) |
NO |
|
WiFi |
StandardSingle frequency WiFi6(OptionalDual-bandWiFi6) |
|||
|
Bluetooth |
WiFi6 standard BT 5.2 |
|||
|
HP& MIC |
1-way 4-segment integrated 3.5mm socket for earphones |
|||
|
Power amplifier |
1 channel8 euro3W dual audio amplifier output(Built-in 8 euro 3W speaker, optional) |
|||
|
USB |
2USB socket, 2 USB hosts, 1 USB OTGsocket |
|||
|
Serial port |
2-way TTL, 2-way RS232, 2-way RS485(Optional 6 TTL or 4 RS232) |
|||
|
4G/5G(Optional) |
EC25EFA/EC25EUXGR/EC25JFA/EC25AUXGR/EC25AFXGA/EC25AUXGR/EG25GGB 4G module with GPSclick to buy |
|||
|
GPS(Optional) |
Need 4G module,Supports dual positioning of Beidou and GPSclick to buy |
|||
|
POE(Optional) |
One built-in POE module, which supports POE power supply for the RJ45 network port |
|||
|
SIM |
1-way Micro SIM card slot |
|||
|
TF |
1-way self-ejecting TF card socket, up to 256GB TF card support |
|||
|
GPIO |
4-way GPIO signal |
|||
|
LED |
4-way, power light, running indicator light, WiFi indicator light, 4G/5G network indicator light |
|||
|
RTC |
Ultra-low power RTC circuit (CR1220 button battery), support timing switch |
|||
|
User buttons |
Reset key, return key, volume+and volume -, burn key |
|||
|
Source |
1 circuit, DC12V ± 5%/DC24V ± 5% power supply, DC 2P-3.81MM |
|||
|
Operating system |
Allwinner A133P |
Rockchip RK3288 |
RockchipRK3568 |
RockchipRK3576S |
|
Android |
Android10 |
Android7.1/5.1/6.0/8.1 |
Android11/12/13 |
Android14 |
|
Linux |
Ubuntu18.04/LinuxQT |
Ubuntu-18.04/Debian9/LinuxQT |
Ubuntu-20.04/Debian11/LinuxQT |
Ubuntu-22.04/ Debian12/LinuxQT |
、
